Product Description

TXM1.8X8 Universal I/O Module, 4-20mA,

8 Inputs/outputs signaled with green LED.

8 universal I/O points, individually configurable as:

DI: Message signal, message impulse (with storage function) or counter impulse (25 Hz)
AI: Temperature sensor, DC 0...10 V, or 4...20 mA
AO: DC 0...10 V, 4...20 mA (for 4 I/O points)

Technical Specifications

Operating voltage

DC 22.5…26 V

Power consumption

2.2 W

Universal input, signal

4…20 mA

Universal inputs/outputs, number

8

Weight (net)

0.194 kg

Dimensions (W x H x D)

64 x 77.5 x 98 mm
