Product Description

PXC00-E.DSystem controller BACnet/IP

The LonWorks system controller of this series allows you to connect LonWorks devices such as Desigo RXC room controllers and third-party devices. Depending on the used expansion module the system controller connect up to 60 or 120 LonWorks devices / RXC room controllers.

BTL tested BACnet communication on LonTalk, PTP or IP according to BACnet standard (rev 1.12 - as of Desigo V6.0) incl. B-BC profile
AMEV profiles AS-A and AS-B according to guide line 'BACnet 2011 - Version 1.2 (as of Desigo V6.0)'

Technical Specifications

Operating voltage

AC 24 V

Frequency

50/60 Hz

Communication

Bus: BACnet / IP

Battery life

4 years

Memory

Flash: 32 MB , SDRAM: 64 MB

Degree of protection

IP20

Dimensions (W x H x D)

192 x 74 x 96 mm

PXC001-E.D	PXC series system controller of BCAnet/IP protocol
PXC00-E.D	BPZ:PXC00-E.DTRABACnetIP System Controller
PXC00-E96.A	BPZ:PXC00-E96.APXCMODULAR controller
PXC00-PE96.A	BPZ:PXC00-PE96.APXCMODULAR controller
PXC100-E96.A	BPZ:PXC100-E96.APXCMODULAR controller with FLN interface
PXC100-PE96.A	BPZ:PXC100-PE96.APXCMODULAR controller with FLN interface and TX-IO interface
PXC16.2-E.A	S55374-C281 16-point programmable controller
PXC16.2-EF32.A	S55374-C282 16-point programmable controller comes with FLN authorization
PXC16.2-P.A	BPZ:PXC16.2-P.APXC controller
PXC16.2-PE.A	BPZ:PXC16.2-PE.APXC controller
PXC16.3-UCM.A	S55374-C283 16-point programmable unit device controller
PXC24.2-E.A	S55374-C284 24-point programmable controller
PXC24.2-EF32.A	S55374-C285 24-point programmable controller comes with FLN authorization
PXC24.2-ER.A	BPZ:PXC24.2-ER.APXC controller
PXC24.2-ERF.A	BPZ:PXC24.2-ERF.APXC controller
PXC24.2-P.A	BPZ:PXC24.2-P.APXC controller
PXC24.2-PE.A	BPZ:PXC24.2-PE.APXC controller
PXC24.2-PEF.A	BPZ:PXC24.2-PEF.APXC controller
PXC24.2-PEF32.A	BPZ:PXC24.2-PEF32.AEthernet programmable controller, comes with FLN authorization
PXC24.2-PER.A	BPZ:PXC24.2-PER.APXC controller
PXC24.2-PERF.A	BPZ:PXC24.2-PERF.APXC controller
PXC24.2-PR.A	BPZ:PXC24.2-PR.APXC controller
PXC24.3-UCM.A	S55374-C286 24-point programmable unit device controller
PXC3.E16A-200A	Room Controller BACnet/IP and DALI
PXC3.E72-100A	PXC3 room intelligent controller, BACnet/IP, support up to 4/8 room division
PXC3.E72A-200A	Room controller BACnet / IP and DALI, up to 4 rooms / 8 room dividers
PXC3.E75-100A	PXC3 room intelligent controller, BACnet/IP, supports up to 8/16 room divisions
PXC3.E75A-200A	Room controller BACnet / IP and DALI, up to 8 rooms / 16 room dividers
PXC36-E.A	BPZ:PXC36-E.APXC36 controller
PXC36-EF.A	BPZ:PXC36-EF.APXC36 controller
PXC36-PE.A	BPZ:PXC36-PE.APXC36 controller
PXC36-PEF.A	BPZ:PXC36-PEF.APXC36 controller
PXC4.E16	PXC4.E16 PXC4 series programmable controller (Ethernet)
PXC4.E16S	S55375-C108 Building controller (16-point Ethernet without MDBS)
PXC4.M16	PXC4.M16 PXC4 series programmable controller (bus type)
PXC4.M16S	S55375-C109 Building controller (16-point bus type without MDBS)
PXC5.E003	PXC5.E003 PXC5.E003 Modular Programmable Controller (Ethernet)
PXC7.E400L	S55375-C105 Building controller (PXC7 large project points)
PXC7.E400M	S55375-C110Building controller (item points in PXC7)
PXC7.E400S	S55375-C111Building controller (PXC7 small item points)
