Voltage AC/DC AC/DC 24 V
Power consumption (running) 4 W
Power consumption (holding) 2 W
Power Consumption For Wire Sizing 6 VA
Connection Supply Control Cable 1 m, 3x 0.75 mm²
Torque 40 Nm
Control type Open/close
Direction Of Motion Motor selectable with switch 0 (ccw rotation) / 1 (cw rotation)
Manual override With push-button, can be locked
Angle of rotation 95
Running time (motor) 150 s / 90°
Mechanical interface Universal shaft clamp reversible 12...26.7 mm
Protection category IP54
Degree Of Protection NEMA NEMA 2
Enclosure Type UL Enclosure Type 2
Ambient Temperature -30...50°C [-22...122°F]
SM24A-MOD Rotary actuator, 20 Nm, AC/DC 24 V, BACnet MS/TP, Modbus RTU, MP-Bus, 2...10 V, 150 s (86...346 s), IP54
SM24A-SR Rotary actuator, 20 Nm, AC/DC 24 V, 2...10 V, 150 s, IP54
SM24A-TP Rotary actuator, 20 Nm, AC/DC 24 V, Open/close, 3-point, 150 s, IP54, Terminals
SM24A-VST Rotary actuator for VRU, 20 Nm, AC/DC 24 V, 120 s, IP54
SM230P Rotary actuator (RobustLine), 20 Nm, AC 100...240 V, Open/close, 3-point, 150 s, IP66/67
SM230PSR Rotary actuator (RobustLine), 20 Nm, AC 100...240 V, 2...10 V, 150 s, IP66/67
